یک آموزش ساده برای مونتاژ بردهای میکروکنترلری
تو این آموزش یه میکرو ۱۷۶ پایه h743 از ابتدا تا انتها در زمان زیر ۵ دقیقه مونتاژ میشه
نکات داده شده در این آموزش فقط برای بردهای نو که روی اونها میکرو مونتاژ نشده معتبر هست
در مورد بردهای تعمیری که میکرو تعویض میشود کافیست بعد از تمیز و یکدست کردن تمام پدها و فیکس کردن میکرو حتما تمام پایه های میکرو با هات ایر گرم شود و با فشار آرام با پنس روی میکرو آنرا به برد بچسبانیم …
انتقال تصویر دوربین ip با رزولوشن ۶۴۰ در ۴۸۰ بصورت jpeg با پروتکل اترنت به برد سری h743iit6 و نمایش تصویر لایو بروی السیدی ۷ اینچ ۸۰۰ در ۴۸۰
توجه کنید تو این پروژه امکان عکس برداری از صفحه و ذخیره آن بروی sd card هم وجود دارد
استفاده از دوربین ip در پروژه ها این مزایا را دارد که میتوان محدودیت فاصله بین دوربین و برد را تا ۱۰۰ متر افزایش داد برخلاف اینترفیس dcmi داخلی میکرو
مراحل انتقال تصویر به این شکل میباشد :
اب…
این برد که توسط این مجموعه به درخواست یکی از دوستان طراحی شده صرفا جهت آشنایی با عملکرد یه دستگاه صنعتی که ممکنه در هر ساختمانی وجود داشته باشه هستش
اجزای اصلی پروژه:
میکرو سری stm32f051k8t6
قابلیت کنترل ماکزیمم ۳۶ عدد ریسه led که ۱۲ ولتی هستن که توسط شیفت رجیستر hc595 کنترل میشه
کنترل ۱۰۰۰ عدد led برنامه پذیر ws2812 یا ws2815 با مسیر تغذیه جدا
دارای دو عدد ورودی سنسور تشخیص حرکت
دارای یک پورت rs485 برلی ارتباط با س…
برد plc-hmi با قابلیت های زیر
قابلیت مونتاژ انواع سری h743 و f767 و f429 سری ۱۷۶ پایه
دارای ۸ کانال خروجی رله ای
دارای ۴ خروجی ۴ تا ۲۰ میلی امپر
دارای ۸ کانال ورودی انالوگ
دارای ۸ کانال دیجیتال ورودی با ایزولاسیون
دارای پورت usb و اترنت و can و rs485 و ماژول gsm
دارای خروجی السیدی ۵۰ پین ۷ اینچ با تاچ مقاومتی و خازنی gt911
ورودی تغذیه ۲۴ ولت
کور برد جدید سری ۱۷۶ پایه با قابلیت مونتاژ تمام سری های h743 , f429 , f767 با ابعاد 5x5
بعد از تست نهایی اطلاعات و مشخصات کامل اعلام میگردد
کانال ما @zetaboard
تماس با ما @zataboard
با سلام خدمت دوستان و همکاران گرامی
با آرزوی سلامتی برای همه عزیزان با توجه به شرایط کشور جهت سفارش با شماره زیر تماس بگیرید
همچنین کانال و اکانت این مجموعه در اپلیکیشن بله بروی شماره زیر فعال میباشد
۰۹۱۹۲۳۸۶۱۳۳ رحیمی
https://ble.ir/ZetaBoard
مدار کاربردی و تست شده بخش بک لایت و ولتاژ بالا قسمت السیدی
توضیحات:
مقدار ولتاژ ورودی مدار از ۳.۳ ولت تا ۵.۵ ولت میباشد
ورودی فعال کردن مدار توسط ترانزیستور کنترل میشود و در حالت عادی فعال میباشد
مدار اصلی بخش سوییچینگ با توجه به جریان ثابت بودن درایو بک لایت در خروجی VLED ما ولتاژ مورد نیاز بک لایت السیدی رو خواهیم داشت .
برای السیدیهای ۷ اینچ حدود ۹.۷ ولت و برای السیدیهای ۴.۳ حدود ۲۴ ولت
نکته اساسی در این مدار…
برد جدید STM32F429ZGT6 با امکانات کامل
میکرو کنترلر قدرتمند و اورجینال سری STM32F429 با 180 مگاهرتز فرکانس کاری و یک مگ حافظه فلش و پکیج LQFP-144
STM32F429ZGT6 MCU 180Mhz
LCD RGB 40&50 PIN up to 1024x782 resolution
STemwin
Resistive Touch 4 pin xpt2046
Touch capasitive 6&12 pin
256Mb SDRAM W9825G5J
1Mb NAND Flash K9F1G08U0C
16Mb spi flash W25Q16
Can SN65HVP230
Rs485 SP3485
Usb host/otg
5v input Voltage
1 Key and 1 …
Signed Mehdi Rahimi
